1. Product outline
1.1 Usage of product
This product is a multi-AC transducer for a high-speed response suitable for power control.
The analog output of current (average of each phase current), voltage (3-phase 3-wire：the average of each line
voltage, average of 3-phase 4-wire：each phase voltage), power, reactive power, and frequency measurement is possible,
by connecting with one circuit of electric power system,
1.2 Features of product
● 120×120×130mm, Approx. 800g. Small and lightweight.
● DIN rail installation correspondence.
● Active power, reactive power, frequency, with measurement range selection change.
● The response time is high-speed. 〔Current. Voltage, Active power, Reactive power：Less than input 1 cycle
＋10ms /99％， Frequency：Less than 1 second /99％〕
● As an option, hydrogen-sulfide (H
2S) gas countermeasure goods can be made.
● The product whose auxiliary supply is DC24V conforms to CE marking. (The product whose auxiliary supply are
AC85～253V and DC80～143V does not conform to CE marking.)
● RoHS instruction conformity product.
1.3 Composition of type
(1)
Mark Series name
HSQT2 HSQT2 series
(2)
Mark Outline dimension (mm)
93 120×120×130
(3)
Mark Contents
A With auxiliary supply
(4)
Mark Number of measurement factors
5 5
(5)
Mark Kind of circuit
33 3-phase 3-wire circuit
34 3-phase 4-wire circuit
(6)
Mark Output method
1 DC output
(1) (2) (3)
(4)
(5)
(6)
HSQT2
－
93
A
－
5
－
33
－
1
