Daiichi Electronics HSQT2-93A - CE Marking

Q-208-081
8
2.5 CE marking (Only auxiliary supply DC24V specification product.)
(1) Conformity technical standard
・EMC conformity technical standard
EMI(Emission) EN61000-6-4
EMS(Immunity) EN61000-6-2
・Safety technical standard
EN61010-1 CATⅢ(Maximum circuit voltage, 300V)，Pollution degree 2
(2) Specification according to EMC test item
EMC test item Limits
Conformity
technical standard
EMI
Electromagnetic
radiation
disturbance
Frequency band Quasi-peak 10m distance
EN61000-6-4：2001
EN55011：1998
classA，Group1
30 ～ 230MHz 40dB(μV/m)
230 ～ 1000MHz 47dB(μV/m)
EMS
Electrostatic
discharge
Contact discharge
±4kV (Charge voltage)
Air discharge
±8kV (Charge voltage)
After test，
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-2：1995
Radio-frequency
amplitude modulated
electromagnetic
field
Frequency Field strength
During test：
Output variation ±20％
After test：
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-3：2006
80 ～ 1000MHz 10V/m，80％ AM(1kHz)
1.4 ～ 2.0GHz 3V/m，80％ AM(1kHz)
2.0 ～ 2.7GHz 1V/m，80％ AM(1kHz)
Fast transients
Power port ：Line to earth ±2.0kV
Signal port：Line to earth ±1.0kV
After test：
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-4：2004
Surge
Power port ：Line to line ±0.5kV
Signal port：Line to earth ±0.5kV
Signal port：Line to earth ±1.0kV
After test：
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-5：2006
Radio-frequency
common mode
Frequency：0.15
～ 80MHz
Voltage level：10V
80％ AM(1kHz)
During test：
Output variation ±20％
After test：
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-6：1996
Power-frequency
magnetic field
Frequency：50/60Hz
Field strength：30A/m
During test：
Output variation ±20％
After test：
Output variation ±0.5％
EN61000-6-2：2005
EN61000-4-8：1994
(3) Installation environment
Over voltage Category Ⅲ
