Daiichi Electronics HSQT2-93A - Specification Code; Specification; Rating

Q-208-081
4
1.4 Specification code
Input Output factor Output Auxiliary supply
A V
① ② ０－１１１１０１００－ ③ － ④
● Input specification
Mark ① Current input ② Voltage input ( ) is at the 3-phase 4-wire case.
1 0～5A (50/60Hz) 0～150V (0～150/√3V) (50/60Hz) (
５
)
2 0～1A (50/60Hz) －
Note(
５
) Rated voltage is 110V(110/√3 V).
● Output factor specification
The output factor of this product constitutes the next five factors.
Current (average value of each phase current)，Voltage (3-phase 3-wire：The average value of each line voltage，
3-phase 4-wire：The average value of each phase voltage)，Active power，Reactive power，Frequency.
The specification code of output factor specification is fixation as the above.
● Output specification
Mark ③ A，V，W，var，Hz output signal
3 DC0～5V (Over 600Ω)
4 DC0～10V (Over 2kΩ)
5 DC1～5V (Over 600Ω)
8 DC±5V (Over 600Ω)
9 DC±10V (Over 2kΩ)
B DC4～20mA (Below 550Ω)
● Auxiliary supply specification
Mark ④ Auxiliary supply
1
AC85～253V (50/60Hz) (Rated voltage 100/110V，200/220V)
DC80～143V (Rated voltage 100/110V) For both AC and DC uses.
2 DC24V ±15％
2. Specification
2.1 Rating
Item Rating
Input
Voltage
3φ3W：AC100V，110V，115V，120V Designation 50/60Hz
Input consumption VA
：Below 0.25VA
3φ4W：AC100/√3V，110/√3V，115/√3V，120/√3V Designation 50/60Hz
Current AC5A or AC1A Designation 50/60Hz
Input consumption VA
：Below 0.1VA
Auxiliary
supply
AC100/110V，200/220V (AC85～253V) 50/60Hz 13VA
DC100/110V (DC80～143V) Below 10W For both AC and DC uses.
or
DC24V (±15％) Below 10W Designation
Output
5 analog outputs (Current，Voltage，Active power，Reactive power，Frequency)
Between outputs is non-insulation.
DC0～5V (Over 600Ω)
DC0～10V (Over 2kΩ)
DC1～5V (Over 600Ω)
DC±5V (Over 600Ω)
DC±10V (Over 2kΩ)
DC4～20mA (Below 550Ω) Designation
