Daikin McQuay WGZ030DW - Page 59

OMM 1130 59
Units with EEV only
VIEW REFRG Cir 1 (5)
EXV Ctrl = XXX
EXV Pos = XXX.X%
SH Target = XX.XF
TGZ Units Only (R134a)
VIEW REFRG Cir 1 (6)
EXV Ctrl Range
XX.X% ---XX.X%
VIEW REFRG Cir 2 (1)
Evap Press XXX.X psi
Cond Press XXX.X psi
R 134a, R22, R410A R407C
VIEW REFRG Cir 2 (2) VIEW REFRG Cir 2 (2)
Sat Evap XXX.X F Evap Dew XXX.X F
Sat Cond XXX.X F i Cond. Mid XXX.X F
VIEW REFRG Cir 2 (3)
SuctionTemp=XXX.XF
Surperheat = XXX.XF
EvapApproach= XX.XF
TGZ Only (R134a)
VIEW REFRG Cir 2 (4)
LiqLineTemp=XXX.XF
Subcooling = XXX.XF
CondApproach= XX.XF
Units with EEV only
VIEW REFRG Cir 2 (5)
EXV Ctrl = XXX
EXV Pos = XXX.X%
SH Target = XX.XF
TGZ Units Only (R134a)
VIEW REFRG Cir 2 (6)
EXV Ctrl Range
XX.X% ---XX.X%
