60 WGZ030D through WGZ200D OMM 1130
Water Cooled = Y Only or
TGZ Unit (R134a)
VIEW TOWER (1)
Stages ON = 1 of 2
EntCondTemp = XXX F
Setpoint = XXX F
The first Stages ON value is the number of fan stages ON. The second number is the Tower Stages
setpoint (0 if Tower Control = None). This screen shows the number of tower fans “on” for each circuit.
This screen will show the fans “on” whether they are actually connected to and controlled by the
MicroTech II controller or not.
Water Cooled = Y Only or
TGZ Unit (R134a)
VIEW TOWER (2)
Bypass Valve = XXX%
VFD Speed = XXX%
The Bypass Valve value shall be “None” (in place of XXX%) if the Valve/VFD Control setpoint = None
or VFD Stage. The VFD Speed value shall be “None” if the Valve/VFD Control setpoint = None, Valve
Setpoint, or Valve Stage.
Water Cooled = N Only
VIEW FANS (1)
Fans On Circuit#1 =XX
Fans On Circuit#2 =XX
This screen shows the number of air-cooled condenser fans “on” for each circuit. This screen will show
the fans “on” whether they are actually connected to and controlled by the MicroTech II controller or not.
VIEW FANS (2)
Stg Error Up Down
Cir 1 = XXX XXX
Cir 2 = XXX XXX
VIEW FANS (3)
Sat Cond Target =
XXX.X
Screen Definitions – ALARM
ALARM ACTIVE (X)
Time Date
Alarm Description
If the unit is off on a shutdown alarm or running, but in a limit alarm condition, the cause and date will
appear in the upper screen. If there is a simultaneous occurrence of more than one alarm, the others will
appear in additional screens below the first one, accessed by the DOWN ARROW.
OR
ALARM ACTIVE (X)
No more alarms
ress ENTER to clear
all active alarms
