SET UNIT SPs (8)
CLOCK
dd/mmm/yyyy
hh:mm:ss
SET UNIT SPs (9) SET UNIT SPs (9) SET UNIT SPs (9)
Units = F/psi Units = F/psi Units = F/psi
Lang = ENGLISH Lang = ENGLISH Lang = ENGLISH
Refrig = None Refrig = R22 Refrig = R407C
SET UNIT SPs (9) SET UNIT SPs (9)
Units = F/psi Units = F/psi
Lang = ENGLISH Lang = ENGLISH
Refrig = R410A Refrig = R134a
Refrigerant type is factory-set.
SET UNIT SPs (10)
Protocol = Modbus
Ident Number=001
Baud Rate=9600
BAS interface settings, available mid-2003.
SET UNIT SPs (11)
Evap Press Sensor
Cir 1 Offset XX.X psi
Cir 2 Offset XX.X psi
The pressure offsets on menus 11 and 12 and the temperature offsets on menus 10, 11 and 12 correct the
controller's display of the parameters. The sensors used in these units have a high degree of repeatability
but may need correction (offset). An accurate pressure gauge or thermometer is used to determine the
correct temperature or pressure. A positive or negative offset value is then entered to make the controller
reading agree with the measured value.
SET UNIT SPs (12)
Cond Press Sensor
Cir 1 Offset XX.X psi
Cir 2 Offset XX.X psi
SET UNIT SPs (13) SET UNIT SPs (13)
Evap Leaving Water LWT Sensors
Temperature Sensor Evap Offset = 00.0
o
F
Offset= 00.0
o
F Cond Offset = 00.0 °F
TGZ Units (Refrig = R134a)
SET UNIT SPs (14) SET UNIT SPs (14)
OAT/Cond Lvg Water LWT Sensors
Temperature Sensor Evap Offset = 00.0
o
F
Offset= 00.0
o
F Cond Offset = 00.0 °F
