64 WGZ030D through WGZ200D OMM 1130
SET UNIT SPs (15)
Suction Temp Sensor
Cir1 Offset 00.0 °F
Cir2 Offset 00.0 °F
WGZ Unit (R22,R407C,R410A) TGZ Unit (Refrig = 134a)
SET UNIT SPs (16) SET UNIT SPs (16)
Clg ResType = X Liq Line Temp Sensors
Clg MaxRes = XX.X ºF
Circ1 Offset = 00.0 ºF
Circ2 Offset = 00.0 ºF
WGZ Unit (R22,R407C,R410A) TGZ Unit (Refrig = 134a)
SET UNIT SPs (17) SET UNIT SPs (17)
ENTER PASSWORD: XXXX Clg ResType = X
Active Password
Clg MaxRes = XX.X ºF
Level: None
Clg StrtRes = XX.X ºF
TGZ Unit in Cooling Mode . TGZ Unit in Heat Mode.
SET UNIT SPs (17) SET UNIT SPs (17)
ENTER PASSWORD: XXXX Htg ResType = X
Active Password
Htg MaxRes = XX.X ºF
Level: None
Htg StrtRes = XX.X ºF
TGZ Unit Heat Mode.
SET UNIT SPs (18)
ENTER PASSWORD: XXXX
Active Password
Level: None
Two four-digit passwords provide OPERATOR and MANAGER levels of access to changeable
parameters. The passwords are preprogrammed into the controller. Either password must be entered
using the ENTER PASSWORD (12) screen before a protected setting can be changed. The operator
password is 0100. The manager level is 2001.
This screen can be accessed either through the SET OTHER menu or by simply pressing the ENTER key
while on one of the SET screens. The controller will automatically go from the screen with the setting
change to this screen. After the correct password has been entered, the controller will automatically
return to the original set screen.
Once a password has been entered, it remains valid for 15 minutes after the last key-press.
Set Compressor Setpoints
SET COMP SPs (1)
# of Compressors = X
Stop-Start =XXmin
Start-Start =XXmin
To Next Page
