OMM 1130 71
Water-cooled = Y
SET TOWER SPs (6)
ValveStartPosition
Min = XXX% @XXXF
Max = XXX% @XXXF
The ValveStartposition is the position of the valve when the unit starts. Default for minimum start
position is 0%, and 100% for maximum position.
Water-cooled = Y
SET TOWER SPs (7)
Valve Control Range
Min = XXX%
Max = XXX%
Defaults are 10% minimum and 90% maximum.
Water-cooled = Y
SET TOWER SPs (8)
PD Control Loop
Error Gain = XX
Slope Gain = XX
Defaults are 25 for both error and slope.
TEST
The test screens are only available when the unit is in TEST mode. Using these screens, any digital
output can be controlled manually.
R22, R407C R410A
TEST UNIT (1) TEST UNIT (1)
Alarm Signal =OFF Alarm Signal =OFF
Evap Pump 1 = OFF Evap Pump 1 = OFF
Evap Pump 2 = OFF
# of Compressors = 4 # of Compressors = 6
TEST UNIT (2) TEST UNIT (1)
Liq Line Sol #1= OFF Liq Line Sol #1= OFF
CompressorHG1 = OFF Compressor HG1 = OFF
1= OFF 3= OFF 1= OFF 3= OFF 5= OFF
# of Compressors = 4 # of Compressors = 6
TEST UNIT (3) TEST UNIT (3)
Liq Line Sol #2=OFF Liq Line Sol #2=OFF
Compressor HG2 = OFF Compressor HG2 = OFF
2= OFF 4= OFF 2= OFF 4= OFF 6= OFF
Water Cooled = ON Water Cooled = OFF
TEST UNIT (4) TEST UNIT (4)
Cond Pump 1 = OFF Fan 1=OFF Fan 3=OFF
Cond Pump 2 = OFF Fan 5/7=OFF
TwrFan1=OFF Fan2=OFF Fan 9=OFF
