Daikin 2AMX40G3V1B User Manual

SiBE121123_A Indoor Unit
Specifications 16
50 Hz, 220 - 230 - 240 V
Model
FTXS20J2V1B FTXS25J2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.0 kW Class 2.5 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
9.4 (332) 9.9 (350) 10.8 (381) 11.9 (420)
M 7.4 (261) 8.2 (290) 7.9 (279) 9.1 (321)
L 5.5 (194) 6.6 (233) 5.2 (184) 6.4 (226)
SL 4.1 (145) 6.2 (219) 3.7 (131) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 18 - 18 - 18 21 - 21 - 21
Power Factor (Rated) % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 9 9
Gross Weight (Gross Mass) kg 13 13
Sound
Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25 41 / 33 / 25 / 22 42 / 35 / 28 / 25
Sound Power Level dB 54 54 57 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm I.D.
φ
14.0, O.D.
φ
18.0
φ
18.0
Drawing No. 3D070564A 3D070565A
Model
FTXS35J2V1B FTXS42J2V1B
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 4.2 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
11.4 (403) 12.4 (438) 11.3 (399) 12.2 (431)
M 8.7 (307) 9.5 (335) 9.0 (318) 9.7 (343)
L 5.8 (205) 6.8 (240) 6.8 (240) 7.3 (258)
SL 4.4 (155) 6.0 (212) 5.9 (208) 6.4 (228)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12 0.11 - 0.11 - 0.11 0.14 - 0.14 - 0.13
Power Consumption (Rated) W 26 - 26 - 26 28 - 28 - 28 24 - 24 - 24 30 - 30 - 30
Power Factor (Rated) % 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2 99.2 - 94.9 - 90.9 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 14 14
Sound
Pressure
Level
H / M / L / SL dB(A) 45 / 37 / 29 / 23 45 / 39 / 29 / 26 45 / 39 / 33 / 30 45 / 39 / 33 / 30
Sound Power Level dB 61 61 61 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm I.D.
φ
14.0, O.D.
φ
18.0 I.D.
φ
14.0, O.D.
φ
18.0
Drawing No. 3D070566A 3D070567A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
