Daikin 2AMX40G3V1B User Manual

Indoor Unit SiBE121123_A
17 Specifications
50 Hz, 220 - 230 - 240 V
Model
FTXS50J2V1B
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color White
Airflow Rates
H
m³/min
(cfm)
11.6 (410) 12.1 (427)
M 9.2 (325) 9.8 (346)
L 7.0 (247) 7.6 (268)
SL 6.0 (212) 6.7 (237)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32
Power Factor (Rated) % 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366
Weight (Mass) kg 10
Gross Weight (Gross Mass) kg 14
Sound
Pressure
Level
H / M / L / SL dB(A) 46 / 40 / 34 / 31 47 / 41 / 34 / 31
Sound Power Level dB 62 63
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm I.D.
φ
14.0, O.D.
φ
18.0
Drawing No. 3D070568A
Model
ATXS20G2V1B ATXS25G2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.0 kW Class 2.5 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
9.4 (332) 9.9 (350) 9.1 (321) 9.8 (346)
M 7.4 (261) 8.2 (290) 7.1 (252) 7.9 (280)
L 5.5 (194) 6.5 (230) 5.2 (182) 6.2 (217)
SL 4.0 (141) 5.5 (194) 3.7 (130) 5.2 (183)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 18 - 18 - 18 21 - 21 - 21
Power Factor % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 9 9
Gross Weight (Gross Mass) kg 13 13
Sound
Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25 38 / 32 / 25 / 22 39 / 34 / 28 / 25
Sound Power
Level
HdB54545455
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D080178 3D080179
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
