SiBE121123_A Indoor Unit
Specifications 18
50 Hz, 220 - 230 - 240 V
Model
ATXS35G2V1B ATXS42G2V1B
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 4.2 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
10.4 (367) 10.6 (374) 9.1 (321) 11.2 (395)
M 7.7 (270) 8.5 (302) 7.7 (273) 9.4 (333)
L 4.8 (170) 6.4 (226) 6.3 (221) 7.7 (271)
SL 3.5 (125) 5.4 (191) 5.4 (190) 6.8 (240)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12 0.11 - 0.11 - 0.10 0.14 - 0.14 - 0.13
Power Consumption (Rated) W 26 - 26 - 26 28 - 28 - 28 24 - 24 - 24 30 - 30 - 30
Power Factor % 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2 99.2 - 94.9 - 100.0 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 14 14
Sound
Pressure
Level
H / M / L / SL dB(A) 42 / 34 / 26 / 23 42 / 36 / 29 / 26 42 / 38 / 33 / 30 42 / 38 / 33 / 30
Sound Power
Level
HdB59595959
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D080180 3D080181
Model
ATXS50G2V1B
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color White
Airflow Rates
H
m³/min
(cfm)
10.2 (360) 11.0 (388)
M 8.6 (305) 9.3 (330)
L 7.0 (246) 7.6 (267)
SL 6.0 (212) 6.7 (236)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32
Power Factor % 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366
Weight (Mass) kg 10
Gross Weight (Gross Mass) kg 14
Sound
Pressure
Level
H / M / L / SL dB(A) 43 / 39 / 34 / 31 44 / 39 / 34 / 31
Sound Power
Level
HdB 60 61
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D081101
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
