Removal of PCBs (Pattern 1)
Si121175
14
Removal Procedu
re
9
Remove the servi
ce
monitor PCB.
10
Lift
up the main PCB.
11
Disconnect t
he
connector
s [S31] [
S32]
[S3
3] [S
71
] [H1
] [H
2].
Step
Procedure
Points
(R6580)
Main PCB
(R2181)
[S31]
[S71]
[S33]
(R10362)
[H1] (yellow)
[S32]
[H2] (blue)
(R10363)
15
17
