Si12-714 Specifications
Specifications 21
Wall Built-in Type
50Hz 230V
MODEL FWKG25AVM FWKG35AVM
Rated Capacity 2.5kW class 3.5kW class
Front Panel Color — —
Air Flow Rate
m³/min
(cfm)
H 7.8 (275) 7.7 (272)
M 6.4 (226) 6.3 (222)
L 5.0 (177) 4.9 (173)
SL 4.3 (152) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof / Long life Removable / Washable / Mildew Proof / Long life
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 332×787×191 332×787×191
Packaged Dimensions (H×W×D) mm 250×1,003×409 250×1,003×409
Weight kg 11.5 11.5
Gross Weight kg 16 16
Operation
Sound
H/M/L/SL dBA 36/32/28/25 37/33/30/27
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D047096 3D047097
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
