EDUS39-605 Control Devices
Controls 19
2.4.2 Specifications / Dimensions
Specifications
Dimensions
DCS302C71
DCS302C71
Power supply voltage / frequency AC100~240V ±10% 50/60Hz
Power consumption Max. 8W
Setting data backup Non-volatile memory preserves data semi-permanently
Effects of instantaneous power failure No effect for 20 mili-sec. or less
Forced OFF input
Operation on the local side cannot be carried out
during forced OFF input.
 No-voltage normal open contact
 Micro-current contact capable of handling 16VDC and approx. 10mA.
 Max. 492 ft cable length
Power supply for schedule timer Power can be supplied to schedule timer. (Max. 1 unit)
Operating ambient temperature / humidity condition -5~40°C, 95% RH or less (no condensation)
Size (width × height × depth) 7 1/8×4 3/4×2 9/16 exposed portion of front panel: 5/8 (Unit: Inch)
Machine Weight (Mass) Approx. 0.95 lbs
Unit (in.)
7 1/8
5/8 3 5/8
3/16
5 3/8
3 5/16
1 15/16
4 3/4
2 13/16
C:3D043353
