Temperature Rise Range
208 240 480 208 240 480
DAX0904**
15
2800 12 16 16
DAX1204**
15
3800 9 12 12
2900 12 16 16 3900 9 12 12
3000 11 15 15 4000 9 12 12
3100 11 15 15 4100 9 12 12
3200 10 14 14 4200 8 11 11
20
2800 16 22 22
20
3800 12 17 17
2900 16 21 21 3900 12 16 16
3000 16 21 21 4000 12 16 16
3100 16 20 20 4100 12 15 15
3200 15 20 20 4200 11 15 15
30
2800 24 32 32
30
3800 19 25 25
2900 23 31 31 3900 18 24 24
3000 23 30 30 4000 18 24 24
3100 21 29 29 4100 17 23 23
3200 21 29 29 4200 17 23 23
1. Above table are calculated with both stages of electric heat engaged (2-stage heat systems). Divide the temperature rise from the table by 2 for 1st stage
operaon for systems using staged electric heat.
2. Temperature rise data are in Degrees Fahrenheit.
