Daikin DR80SN - Airflow Tables

25
 
0.1 0.2 0.3 0.4
CFM
CFM CFM CFM CFM Watts CFM Watts CFM Watts CFM Watts
F01 658 585 545 495 444 83 390 88 332 94 151 49
F02 749 697 652 607 554 102 509 108 459 113 406 120
F03 925 881 840 800 760 150 721 157 681 162 645 169
F04^ 882 841 800 760 719 138 678 144 641 151 602 157
F05 1330 1295 1273 1251 1223 358 1195 366 1168 375 1142 385
F06 1130 1090 1059 1022 991 230 957 237 926 246 895 255
F07 1158 1113 1090 1057 1024 247 996 258 964 264 935 271
F08 1270 1235 1208 1179 1147 304 1119 312 1088 322 1060 329
F09 1417 1380 1359 1336 1314 408 1288 419 1261 430 1238 440
F01 659 599 542 490 437 89 383 95 320 102 N/A N/A
F02 1268 1221 1188 1154 1122 336 1091 344 1060 353 1029 361
F03 1087 1044 1008 973 938 234 905 242 871 249 841 257
F04^ 1118 1070 1033 997 963 243 929 251 896 260 865 267
F05 1308 1262 1224 1197 1167 332 1141 341 1117 352 1089 361
F06 868 823 780 741 699 148 662 154 624 160 584 167
F07 922 877 835 795 757 165 718 173 679 180 642 187
F08 1382 1341 1311 1291 1263 435 1234 443 1206 453 1177 464
F09 1492 1448 1409 1381 1354 460 1332 470 1310 481 1288 491
F01 764 695 630 559 485 95 415 102 358 109 N/A N/A
F02 1287 1235 1191 1147 1104 244 1062 252 1020 263 979 272
F03 1339 1301 1258 1217 1174 270 1131 279 1090 289 1048 299
F04^ 1396 1346 1298 1257 1217 289 1175 299 1135 308 1098 319
F05 1185 1135 1088 1040 992 203 947 211 901 219 855 227
F06 1500 1460 1420 1360 1380 337 1294 353 1256 365 1219 380
F07 1591 1539 1493 1454 1416 391 1379 402 1347 412 1311 424
F08 1675 1622 1583 1545 1510 447 1474 459 1440 473 1402 482
F09 1790 1741 1701 1668 1631 531 1599 546 1567 560 1532 570
F01 710 646 580 515 432 79 367 85 314 90 274 95
F02 1298 1255 1216 1178 1140 242 1102 253 1067 263 1028 273
F03 1209 1166 1124 1083 1045 208
1005 217 964 227 923 236
F04^ 1138 1091 1045 1001 959 181 920 188 876 197 832 208
F05 1391 1352 1314 1278 1241 288 1209 298 1175 311 1140 242
F06 977 931 880 836 785 135 734 142 683 151 626 158
F07 1036 985 940 895 848 150 799 158 751 167 705 175
F08 1456 1414 1376 1341 1302 315 1270 327 1238 337 1200 352
F09 1533 1488 1452 1415 1383 360 1350 370 1317 381 1286 393
F01 841 657 595 522 439 90 367 97 315 102 N/A N/A
F02 1141 1089 1045 1001 958 192 914 200 869 207 823 214
F03 1311 1267 1226 1189 1150 253 1114 264 1072 275 1034 283
F04^ 1395 1347 1309 1270 1233 291 1199 302 1164 312 1125 323
F05 1490 1447 1407 1373 1336 339 1303 351 1269 360 1237 373
F06 1553 1510 1469 1435 1401 372 1368 384 1335 395 1300 408
F07 1593 1548 1508 1474 1440 392 1409 405 1376 415 1343 429
F08 1776 1735 1695 1661 1628 514 1601 529 1570 542 1542 555
F09 1853 1812 1773 1739 1708 569 1679 585 1650 599 1623 614
F01 837 752 671 576 501 100 426 107 361 113 315 119
F02 1316 1270 1218 1166 1114 217 1061 227 1000 238 962 251
F03 1353 1323 1286 1235 1183 242 1131 253 1085 263 1040 275
F04^ 1587 1544 1506 1459 1416 333 1372 345 1323 358 1281 369
F05 1731 1673 1632 1587 1546 398 1506 414 1463 426 1421 440
F06 1794 1744 1709 1671 1632 444 1591 459 1555 474 1513 489
F07 1861 1805 1761 1720 1681 481 1642 496 1603 509 1565 524
F08 1910 1873 1839 1798 1761 525 1723 545 1686 559 1648 574
F09 2110 2055 2035 2003 1973 700 1946 724 1907 731 1890 750
F01 802 724 637 551 468 87 389 95 342 100 294 106
F02 1405 1356 1308 1262 1210 241 1182 #N/A 1155 252 1102 264
F03 1574 1531 1484 1440 1392 320 1357 331 1306 342 1256 355
F04^ 1619 1575 1526 1489 1446 336 1404 352 1355 361 1313 374
F05 1688 1641 1600 1557 1513 367 1477 383 1428 398 1381 405
F06 1811 1769 1730 1686 1649 443 1610 456 1572 468 1525 482
F07 1857 1812 1774
1733 1697 475 1662 489 1622 505 1586 518
F08 1892 1850 1805 1774 1735 496 1692 511 1658 523 1621 537
F09 2116 2073 2039 2005 1981 675 1945 688 1909 707 1879 728
F01 851 774 692 615 535 105 470 111 411 118 359 124
F02 1677 1629 1583 1540 1498 408 1449 422 1399 436 1349 450
F03 1537 1489 1444 1404 1365 335 1322 348 1272 360 1211 372
F04^ 1416 1365 1315 1267 1220 277 1163 285 1106 296 1048 306
F05 1154 1098 1043 983 932 177 874 187 819 196 755 205
F06 1806 1764 1729 1688 1654 489 1615 503 1578 519 1535 535
F07 1869 1816 1773 1731 1693 521 1661 535 1629 548 1589 560
F08 1947 1903 1865 1833 1802 604 1769 621 1743 640 1708 654
F09 2107 2066 2030 1996 1963 734 1932 753 1899 772 1867 788
DR80SN0403A*
Y/Y1, Y2, G
DR80SN0603A*
Y/Y1, Y2, G
FAN & COOLING AIFLOW
MODEL
THERMOSTAT
CALL
TAP #
EXTERNAL STATIC PRESSURE (INCHES WATER COLUMN)
0.5
0.6
0.7
0.8
DR80SN0604B*
Y/Y1, Y2, G
DR80SN0803B*
Y/Y1, Y2, G
DR80SN0804B*
Y/Y1, Y2, G
DR80SN1205D*
Y/Y1, Y2, G
DR80SN0805C*
Y/Y1, Y2, G
DR80SN1005C*
Y/Y1, Y2, G
NOTE:
FURNACE MODEL
Y2 Y1
DR80SN0805C* F08 F02
DR80SN1205D* F06 F05
RECOMMENDED AIRFLOW SPEEDS FOR
CONNECTION WITH 2 STAGE OUTDOOR
MODELS
1. F04 is Default Speed for Y/Y1
2. F05 is Default Speed for Y2
3. F01 is Default Speed for G
4. For a single-stage outdoor unit, the Y connection from the thermostat can be connected to the Y/Y1
or Y2 connection on the furnace control module. A call for cooling will energize that connection on the
furnace control module. The desired cooling fan speed should be adjusted for the furnace control
module connection used (Y1 or Y2) to provide the correct cooling airflow.
