Daikin DRC036 - Appendix A Blower Performance Tables

17




 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 978 525 0.04

0.2 998 558 0.04
0.4 - - - 0.4 - - -
0.6 - - - 0.6 - - -
0.8 - - - 0.8 - - -
1.0 - - - 1.0 - - -

0.2 1269 568 0.18

0.2 1295 643 0.21
0.4 1176 621 0.20 0.4 1200 702 0.23
0.6 1084 696 0.22 0.6 1106 776 0.25
0.8 991 760 0.24 0.8 1011 851 0.27
1.0 898 828 0.27 1.0 916 901 0.29

0.2 1115 568 0.15

0.2 1138 604 0.16
0.4 1095 620 0.17 0.4 1117 660 0.18
0.6 1004 695 0.19 0.6 1024 739 0.20
0.8 899 760 0.21 0.8 917 808 0.22
1.0 770 827 0.22 1.0 786 880 0.24

0.2 1365 640 0.23

0.2 1393 681 0.24
0.4 1262 698 0.25 0.4 1288 743 0.27
0.6 1166 763 0.27 0.6 1190 812 0.29
0.8 1034 839 0.30 0.8 1055 893 0.32
1.0 995 867 0.31 1.0 1015 922 0.33

0.2 - - -

0.2 - - -
0.4 1378 756 0.32 0.4 1406 804 0.34
0.6 1291 816 0.35 0.6 1317 868 0.37
0.8 1197 873 0.37 0.8 1221 929 0.40
1.0
1078 938 0.40
1.0
1100 998 0.43
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating



 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 940 533 0.11

0.2 961 540 0.11
0.4 729 642 0.13 0.4 751 654 0.13
0.6 562 735 0.15 0.6 589 740 0.15
0.8 396 765 0.15 0.8 404 813 0.16
1.0 - - - 1.0 - - -

0.2 1488 685 0.28

0.2 - - -
0.4 1374 751 0.30 0.4 1387 759 0.31
0.6 1233 843 0.34 0.6 1262 837 0.34
0.8 1072 914 0.37 0.8 1105 919 0.37
1.0 950 974 0.39 1.0 998 976 0.39

0.2 1216 609 0.18

0.2 1237 614 0.18
0.4 1065 708 0.21 0.4 1095 704 0.21
0.6 906 784 0.23 0.6 924 794 0.24
0.8 766 854 0.25 0.8 792 863 0.26
1.0 627 882 0.26 1.0 640 937 0.28

0.2 1488 685 0.28

0.2 - - -
0.4 1374 751 0.30 0.4 1387 759 0.31
0.6 1233 843 0.34 0.6 1262 837 0.34
0.8 1072 914 0.37 0.8 1105 919 0.37
1.0 950 974 0.39 1.0 998 976 0.39

0.2 - - -

0.2 - - -
0.4 1490 782 0.36 0.4 - - -
0.6 1369 859 0.40 0.6 1401 860 0.40
0.8 1220 934 0.43 0.8 1252 944 0.44
1.0
1102 992 0.46
1.0
1120 1006 0.47
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating
