30
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN W.C.
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
N W.C.
SCFM RPM BHP
C
0.2
1023 525 0.11
H
0.2
1930 814 0.55
0.4 887 617 0.13 0.4 1860 842 0.57
0.6 732 700 0.15 0.6 1798 885 0.60
0.8 602 773 0.17 0.8 1730 929 0.63
1.0 456 837 0.18 1.0 1653 976 0.66
1.2 350 885 0.19 1.2 1575 1028 0.70
1.4 - - - 1.4 1445 1095 0.74
1.6 - - - 1.6 1343 1148 0.78
1.8 - - - 1.8 1255 1191 0.81
2.0
- - -
2.0
1181 1233 0.84
C
0.2
1587 685 0.29
H
0.2
2012 850 0.64
0.4 1507 739 0.32 0.4 1944 886 0.66
0.6 1425 795 0.34 0.6 1880 918 0.69
0.8 1337 851 0.36 0.8 1819 951 0.71
1.0 1189 932 0.40 1.0 1743 993 0.74
1.2 1069 991 0.42 1.2 1670 1038 0.78
1.4 989 1042 0.45 1.4 1568 1092 0.82
1.6 1056 827 0.35 1.6 1448 1154 0.87
1.8 - - - 1.8 1354 1201 0.90
2.0
- - -
2.0
1293 1228 0.92
C
0.2
1930 814 0.55
H
0.2
- - -
0.4 1860 842 0.57 0.4 2016 894 0.73
0.6 1798 885 0.60 0.6 1948 936 0.77
0.8 1730 929 0.63 0.8 1894 968 0.79
1.0 1653 976 0.66 1.0 1823 1009 0.83
1.2 1575 1028 0.70 1.2 1749 1056 0.87
1.4 1445 1095 0.74 1.4 1661 1102 0.90
1.6 1343 1148 0.78 1.6 1537 1167 0.96
1.8 1255 1191 0.81 1.8 1435 1218 1.00
2.0
1181 1233 0.84
2.0
1348 1261 1.04
C
0.2
- - -
H
0.2
- - -
0.4 2016 894 0.73 0.4 - - -
0.6 1948 936 0.77 0.6 - - -
0.8 1894 968 0.79 0.8 1964 988 0.87
1.0 1823 1009 0.83 1.0 1896 1024 0.90
1.2 1749 1056 0.87 1.2 1823 1068 0.94
1.4 1661 1102 0.90 1.4 1744 1115 0.98
1.6 1537 1167 0.96 1.6 1645 1172 1.03
1.8 1435 1218 1.00 1.8 1523 1233 1.09
2.0
1348 1261 1.04
2.0
1434 1274 1.12
C
0.2
- - -
H
0.2
- - -
0.4 - - - 0.4 - - -
0.6 - - - 0.6 - - -
0.8 - - - 0.8 - - -
1.0 1988 1052 1.00 1.0 1988 1052 1.00
1.2 1916 1092 1.04 1.2 1916 1092 1.04
1.4 1846 1137 1.08 1.4 1846 1137 1.08
1.6 1766 1180 1.12 1.6 1766 1180 1.12
1.8 1651 1243 1.18 1.8 1651 1243 1.18
2.0 1547 1289 1.23 2.0 1547 1289 1.23
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN W.C.
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
N W.C.
SCFM RPM BHP
C
0.2
1044 558 0.12
H
0.2
1969 865 0.59
0.4 905 656 0.14 0.4 1898 895 0.61
0.6 747 745 0.16 0.6 1835 940 0.64
0.8 614 822 0.18 0.8 1765 987 0.67
1.0 465 890 0.19 1.0 1687 1037 0.70
1.2 357 941 0.20 1.2 1607 1092 0.74
1.4 - - - 1.4 1475 1163 0.79
1.6 - - - 1.6 1371 1220 0.83
1.8 - - - 1.8 1281 1265 0.86
2.0
- - -
2.0
1206 1310 0.89
C
0.2
1619 728 0.31
H
0.2
- - -
0.4 1538 785 0.34 0.4 1983 941 0.71
0.6 1455 845 0.36 0.6 1918 975 0.73
0.8 1364 904 0.39 0.8 1856 1010 0.76
1.0 1213 990 0.42 1.0 1779 1055 0.79
1.2 1091 1053 0.45 1.2 1704 1103 0.83
1.4 1010 1107 0.47 1.4 1600 1160 0.87
1.6 1161 880 0.38 1.6 1477 1226 0.92
1.8 - - 1.8 1382 1276 0.96
2.0
- - -
2.0
1320 1305 0.98
C
0.2
1969 865 0.59
H
0.2
- - -
0.4 1898 895 0.61 0.4 - - -
0.6 1835 940 0.64 0.6 1988 995 0.82
0.8 1765 987 0.67 0.8 1933 1028 0.84
1.0 1687 1037 0.70 1.0 1860 1072 0.88
1.2 1607 1092 0.74 1.2 1785 1122 0.92
1.4 1475 1163 0.79 1.4 1695 1171 0.96
1.6 1371 1220 0.83 1.6 1569 1240 1.02
1.8 1281 1265 0.86 1.8 1464 1294 1.06
2.0
1206 1310 0.89
2.0
1376 1340 1.10
C
0.2
- - -
H
0.2
- - -
0.4 - - - 0.4 - - -
0.6 1988 995 0.82 0.6 - - -
0.8 1933 1028 0.84 0.8 - - -
1.0 1860 1072 0.88 1.0 1935 1088 0.96
1.2 1785 1122 0.92 1.2 1860 1135 1.00
1.4 1695 1171 0.96 1.4 1780 1185 1.04
1.6 1569 1240 1.02 1.6 1679 1245 1.10
1.8 1464 1294 1.06 1.8 1554 1310 1.15
2.0
1376 1340 1.10
2.0
1463 1354 1.19
C
0.2
- - -
H
0.2
- - -
0.4 - - - 0.4 - - -
0.6 - - - 0.6 - - -
0.8 - - - 0.8 - - -
1.0 - - - 1.0 - - -
1.2 1955 1160 1.10 1.2 1955 1160 1.10
1.4 1884 1208 1.15 1.4 1884 1208 1.15
1.6 1802 1254 1.19 1.6 1802 1254 1.19
1.8 1684 1321 1.26 1.8 1684 1321 1.26
2.0 1579 1370 1.30 2.0 1579 1370 1.30
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating
To Next Page
