Daikin Enfinity CCH - Model Nomenclature and Specifications; Model Nomenclature Code Breakdown

Model noMenClature
Category Code Item Code Option Code Designation & Description
Product Category 01 1 W = Water Source Heat Pump
Product Identier 02 2-4 CCH = R410A, Ceiling-Mounted, Standard Range
CCW = R410A, Ceiling-Mounted, Geothermal Range
Design Series (Vintage) 03 5 4 = D Design
5 = E Design
Nominal Capacity 04 6-8 007 = 7,000 Btuh Nominal Cooling
009 = 9,000 Btuh Nominal Cooling
012 = 12,000 Btuh Nominal Cooling
015 = 15,000 Btuh Nominal Cooling
019 = 19,000 Btuh Nominal Cooling
024 = 24,000 Btuh Nominal Cooling
030 = 30,000 Btuh Nominal Cooling
036 = 36,000 Btuh Nominal Cooling
042 = 42,000 Btuh Nominal Cooling
048 = 48,000 Btuh Nominal Cooling
060 = 60,000 Btuh Nominal Cooling
070 = 70,000 Btuh Nominal Cooling
Controls 05 9 B = MicroTech® III Unit Controller
C = MicroTech III Unit Controller w/LonWorks® Communication Module
D = MicroTech III Unit Controller w/BACnet® Communication Module
Voltage 06 10 A = 115-60-1 (Sizes 007- 009 only)
E = 208-230/60/1
J = 265/277-60-1
F = 208-230/60/3
K = 460/60/3*
L = 575/60/3
M = 230/50/1
N = 380/50/3
Return Air 08 12 L = Left
R = Right
Discharge Air 09 13 E = End Discharge
S = Straight Discharge
Blower Motor 10 14-15 01 = Standard PSC
03 = Low Static
04 = ECM
Construction Type 12 18 A = Standard(1/2inchFGinsulation/1"lterrack)
B = Standard with 2" Filter Rack
C = Standard with Compressor Sound Blanket
   D = StandardwithCompressorSoundBlanketand2"lterrack
E = Indoor Air Quality (IAQ) - Closed Cell Insulation
F = IAQ with 2" Filter Rack
G = IAQ with Compressor Sound Blanket
H = IAQ with Compressor Sound Blanket and 2" Filter Rack
J = Sound Package
K = Sound Package w/2" Filter Rack
Heat Exchanger 13 19 C = Copper Inner Tube - Steel Outer Tube
S = Cupronickel Inner Tube - Steel Outer Tube
Drain Pan 19 30-32 YYY = Standard (High Density Polyethylene) HDPE Drain Pan
SYY = Stainless Steel Drain Pan
Refrigerant 20 33 A = R410A
Cabinet Electrical 22 35-37 YYY = Standard (50VA Transformer)
75VA = 75VA Control Transformer
Color 24 39 Y = None (Galvanized)
Agency Listing 26 41 C = ETL, CETL, ARI, MEA
Packaging 27 42 1 = Standard
Product Style 29 44 1 = Style
Notes: * A 460 volt, 3-phase unit that utilize an ECM fan motor will need a 4-wire WYE voltage supply with 3 hot leads and a neutral wire. To power the EC motor with
neutral and one hot for 277/60/1 voltage to the EC motor.
IM 1049-9 4 www.DaikinApplied.com
