Table 2 - EWAD 210E ÷ 410E-SS - HFC 134a - Technical Data
Unit SIze
210
260
310
360
410
Capacity (1)
Cooling
kW
214
256
307
360
413
Capacity control
Type
---
Stepless
Minimum capacity
%
25
25
25
25
25
Unit power input (1)
Cooling
kW
71.7
86.7
111
133
146
EER (1)
---
2.98
2.95
2.77
2.71
2.84
ESEER
---
3.02
3.18
3.05
3.23
3.34
IPLV
---
3.48
3.68
3.57
3.61
3.65
Casing
Colour
---
Ivory White
Material
---
Galvanized and painted steel sheet
Dimensions
Unit
Height
mm
2273
2223
2223
2223
2223
Width
mm
1292
2236
2236
2236
2236
Length
mm
3965
3070
3070
3070
3070
Weight
Unit
kg
2086
2522
2745
2855
2919
Operating Weight
kg
2116
2547
2775
2891
2963
Water heat
exchanger
Type
---
Plate to Plate
Water volume
l
30
25
30
36
44
Nominal water flow rate
l/s
10.22
12.22
14.65
17.21
19.74
Nominal Water pressure drop
kPa
21
48
48
48
45
Insulation material
Closed cell
Air heat exchanger
Type
---
High efficiency fin and tube type
with integral subcooler
Fan
Type
---
Direct propeller type
Drive
---
DOL
Diameter
mm
800
800
800
800
800
Nominal air flow
l/s
21150
32767
32767
31725
31725
Model
Quantity
No.
4
6
6
6
6
Speed
rpm
920
920
920
920
920
Motor input
kW
1.75
1.75
1.75
1.75
1.75
Compressor
Type
---
Semi-hermetic
single screw compressor
Oil charge
l
13
16
19
19
19
Quantity
No.
1
1
1
1
1
Sound level
Sound Power
Cooling
dB(A)
94.2
94.2
94.5
94.5
95.2
Sound Pressure (2)
Cooling
dB(A)
75.1
75.0
75.3
75.3
76.0
Refrigerant circuit
Refrigerant type
---
R-134a
R-134a
R-134a
R-134a
R-134a
Refrigerant charge
kg.
33
46
46
56
60
N. of circuits
No.
1
1
1
1
1
Piping connections
Evaporator water inlet/outlet
"
3
3
3
3
3
Safety devices
High discharge pressure (pressure switch)
High discharge pressure (pressure transducer)
Low suction pressure (pressure transducer)
Compressor motor protection
High discharge temperature
Low oil pressure
Low pressure ratio
High oil filter pressure drop
Phase monitor
Water freeze protection controller
Notes (1)
Cooling capacity, unit power input in cooling and EER are based on the following conditions: evaporator
12/7°C; ambient 35°C, unit at full load operation.
Notes (2)
The values are according to ISO 3744 and are referred to: evaporator 12/7°C, ambient 35°C, full load
operation.
