Daikin FBQ-C - 9 Fan Characteristics

• Split Sky Air • Indoor Units
17
• Indoor Units • R-410A • FBQ-C7VEB
9 Fan characteristics
FBQ35-50C
3TW31218-1
Fan characteristics (1)
Fan characteristics (3)
(airflow auto adjustment)
Fan characteristics (2)
(Field setting with remote control)
External static pressure [Pa]
External static pressure [Pa]
External static pressure [Pa]
Airflow [m
3
/min]Airflow [m
3
/min]
Airflow [m
3
/min]
Range of available air flow rate (H)
L
M
H
Upper limint of ESP by
airflow auto adjustment
Upper limint of ESP by
airflow auto adjustment
Upper limint of ESP
Lower limit of ESP
Upper limint of ESP
(max ESP )
Lower limit of ESP
(std ESP)
Lower limit of ESP
(max ESP)
Upper limint of ESP
(std ESP )
L (max ESP)
M (max ESP)
H (max ESP)
L (std ESP)
H (std ESP)
M (std ESP)
NOTES
1 Fan characteristics as shown are in “fan only” mode.
2 ESP: External static pressure
FBQ60C
3TW31298-1
Fan characteristics (1)
Fan characteristics (3)
(airflow auto adjustment)
Fan characteristics (2)
(Field setting with remote control)
External static pressure [Pa]
External static pressure [Pa]External static pressure [Pa]
Airflow [m
3
/min]Airflow [m
3
/min]
Airflow [m
3
/min]
Range of available air flow rate (H)
L
M
H
Upper limint of ESP by
airflow auto adjustment
Upper limint of ESP by
airflow auto adjustment
Upper limint of ESP
Lower limit of ESP
Upper limint of ESP
(max ESP )
Lower limit of ESP
(std ESP)
Lower limit of ESP
(max ESP)
Upper limint of ESP
(std ESP )
L (max ESP)
M (max ESP)
H (max ESP)
L (std ESP)
H (std ESP)
M (std ESP)
NOTES
1 Fan characteristics as shown are in “fan only” mode.
2 ESP: External static pressure
