Safety devices 35 50 60 71 100 125 140
FBQ
PC Board Fuse 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A 250V 3.15A
PC Board Fuse (Fan Driver) 250V 5A 250V 5A 250V 6.3A 250V 6.3A 250V 6.3A 250V 6.3A 250V 6.3A
Fan Motor Thermal Protector °C
———————
Drain Pump Fuse °C 145 145 145 145 145 145 145
Options
Operation Control
(*1): Electrical heater and humidifier are field supply. These parts should not be installed inside the equipment (refer to installation manual EKRP1B2A)
(*2): If installing an electrical heater, an option PCB for external electrical heater (EKRP1B2) for each indoor unit is required.
(*3): Mounting plate KRP4A96 is required for these options. Maximum 2 option PCB’s can be mounted.
(*4): Decoration panel option EKBYBSD is required for direct mounting of the decoration panel on the unit.
Contents of accessory bag
Item FBQ35,50 FBQ60,71 FBQ100,125,140
Panel related Decoration panel (*4) BYBS45D BYBS71D BYBS125D
Air inlet and air discharge outlet related Air discharge adapter for round duct KDAJ25K56A KDAJ25K71A KDAJ25K140A
Panel related Decoration panel option EKBYBSD
Item FBQ35,50 FBQ60,71 FBQ100,125,140
Remote Control Wired Type BRC1D528 / BRC1E51A
Wireless Type HP BRC4C65
CO BRC4C66
Option BCB for external el. heater, humidifier and/or hour meter (*1), (*3) EKRP1B2A
Adapter for wiring (interlock for fresh air intake fan) (*3) KRP1C64
Wiring adapter for electrical appendices (*3) KRP4A51
Remote sensor KRCS01-4B
Central remote control DCS302CA51
Unified ON/OFF controller DCS301BA51
Schedule timer DST301BA51
Remote ON/OFF and FORCED OFF kit EKRORO3
Mounting plate for adapter PCB KRP4A96
Description
Quantity
FBQ35,50,60,71,100,125,140
Hexagon tapping screw (M5x16) 16
Round plain washer for wood 8
Installation and operation manual 1
Hose band 1
Insulation for joint (GAS) 1
Insulation for joint (LIQUID) 1
Drain hose 1
Drain hose sealing material 1
Sealing material 2
NOTES
