3TW31601-1
EKRORO3
Standard
setting:
’forced off’
Selection of ’FORCED OFF’ and ’ON/OFF’ operation
Input ’ON’ = closed contact.
Remote
controller
T1,T2Switch
Alternative
setting:
’on/off’
Terminal X2M
Connector (White)
connect to indoor
PCB (X30A)
On
Off
On
Off
On
Off
On
Off
unit
INPUT
Operating method
Wire specifications
Forced off On/off operation
Input ’on’ stops operation + disables control Input off→on: starts operation, remote control is still enabled.
Input ’off’ enables control Input on→off: stops operation, remote control is still enabled.
Setting Mode No. First code NO Second code NO
Forced off
12 (22) 1
01
On/off operation
02
Screw to control box
replacing the original
terminal
To Next Page
