8
Application Information
1) Indoor Installation Clearance
Clearancemustbeprovidedfortheindoorunitfromwallandobstaclesasshowningurebelow.
erom ro m5.0erom ro m5.0erom ro m5.0
0.3m or less
3m or more
1m or more
Floor
Obstacle
Beam
The installation place (handling ceiling surface) must be level and the height in the ceiling is 370mm or more.
Unit Installation
Ceiling Opening Size = 890mm
Hanging rod size = 780mm
Ceiling Opening Size = 890mm
Hanging rod size = 710mm
WATER DRAINAGE
PIPING DIRECTION
LED
REFRIGERANT
PIPING DIRECTION
• Measureandmarkthepositionforthehangingrod.Drilltheholefortheanglenutontheceilingandxthehanging
rod.
• The installation template is extended according to temperature and humidity. Check on dimensions in use.
• The dimensions of the installation template are the same as those of the ceiling opening dimensions.
• Beforeceilinglaminatingworkiscompleted,besuretottheinstallationtemplatetotheindoorunit.
NOTE
Be sure to discuss the ceiling drilling work with the installers concerned.
