Daikin FCRN - Technical Specifications

10
Application Information
3) Cable Size
Cooling only
Model Unit
FCRN18FXV1S FCRN24FXV1S FCRN30FXV1S
RN18CXV1S2 RR24CXV1S2 RR30CXV1S2
Power supply cable size
Number of wire
mm² 2.5
3
2.5
3
2.5
3
Interconnection cable size
Number of wire
mm² 2.5
4
2.5
4
2.5
4
Recommended fuse A 16 20 25
Model Unit
FCRN36FXV1S FCRN42FXV1S FCRN45FXV1S
RR36DXV1S2 RR42DXY1S2 RR45DXY1S2
Power supply cable size
Number of wire
mm
2
4.0
3
4.0
5
4.0
5
Interconnection cable size
Number of wire
mm
2
2.5
4
2.5
2.5
2.5
2.5
Recommended fuse A 25 16 20
4) Refrigerant Piping
When the pipe length becomes too long, both the capacity and reliability drop. As the number of bends
increase,resistanceto owofrefrigerantsystem increases,thusloweringcoolingcapacityandasaresult
the compressor may become defective. Always choose the shortest path and follow the recommendation as
tabulated below:
Model
Indoor FCRN18FXV1S FCRN24FXV1S FCRN30FXV1S
Outdoor RN18CXV1S2 RR24CXV1S2 RR30CXV1S2
Max. allowable length, m 30 30 45
Max. allowable elevation, m 15 15 25
Liquid pipe size, mm 6.35 / 1/4” 6.35 / 1/4” 9.52 / 3/8”
Gas pipe size, mm 12.70 / 1/2” 15.88 / 5/8” 15.88 / 5/8”
Model
Indoor FCRN36FXV1S FCRN42FXV1S FCRN45FXV1S
Outdoor RR36DXV1S2 RR42DXY1S2 RR45DXY1S2
Max. allowable length, m 50 50 50
Max. allowable elevation, m 30 30 30
Liquid pipe size, mm / in 9.52 / 3/8” 9.52 / 3/8” 9.52 / 3/8”
Gas pipe size, mm / in 15.88 / 5/8” 15.88 / 5/8” 15.88 / 5/8”
