17
Engineering & Physical Data
Engineering Data - R410A MODEL
MODEL
INDOOR UNIT
FCRN42FXV1S FCRN45FXV1S
OUTDOOR UNIT
RR42DXY1S2 RR45DXY1S2
NOMINAL COOLING CAPACITY
Btu/h 42,000 45,000
W 12300 13200
NOMINAL TOTAL INPUT POWER (COOLING) W 4110 4810
NOMINAL RUNNING CURRENT (COOLING) A 6.92 8.78
EER W/W 3.00 2.74
POWER SOURCE V/Ph/Hz 380-415/3/50
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 2.70 3.05
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 8 WAYS AIR DISCHARGE
OPERATION WIRELESS REMOTE CONTROL
AIR FLOW
HIGH CFM 1120 1120
MEDIUM CFM 1030 1030
LOW CFM 890 890
QUIET CFM 760 760
SOUND PRESSURE LEVEL (H/M/L/SL) dBA 48/45/41/37 48/45/41/37
UNIT DIMENSION [Panel] HEIGHT X WIDTH X DEPTH mm 288 x 840 x 840 [346 x 950 x 950]
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 370 x 916 x 916 [147 x 970 x 1008]
UNIT WEIGHT (UNIT + PANEL) kg 25+5 29+5
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR MOTOR
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE F
RATED INPUT POWER W 200 204
RATED RUNNING CURRENT A 0.88 0.89
MOTOR MAX OUTPUT W 105 105
POLES 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.53 0.51
ROW 2 3
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW CFM 3400 4000
SOUND PRESSURE LEVEL dBA 60 63
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 852 x 1030 x 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 1010 x 1180 x 514
UNIT WEIGHT kg 95 98
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 9.52
GAS mm 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR MOTOR
INDEX OF PROTECTION (IP) IP44
INSULATION GRADE CLASS F
RATED INPUT POWER W 276 406
RATED RUNNING CURRENT A 1.34 1.76
MOTOR OUTPUT W 145 245
POLES 8 6
COMPRESSOR
TYPE SCROLL
OIL TYPE MOBILE EAL ARTIC 22C
OIL AMOUNT cm
3
1951 1656
RATED INPUT POWER W 3634 4200
RATED RUNNING CURRENT A 4.70 6.13
LOCKED ROTOR AMP. A 51.5 74
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.89 0.89
ROW 2 2
CASING COLOUR IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT)
COOLING
INDOOR: 27°C DB/ 19°C WB
OUTDOOR: 35°C DB
