Daikin FDMQ-R Series User Manual

8
FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
Model
Indoor Unit FTX15NMVJU
Outdoor Unit
RXL15QMVJUA
Cooling Heating
Power Supply
1 φ , 60 Hz, 208 - 230 V
Capacity Rated (Min. ~ Max.) kW 4.40 (1.70 ~ 5.40) 5.35 (1.70 ~ 7.20)
Btu/h 15,000 (5,800 ~ 18,400) 18,300 (5,800 ~ 24,600)
kcal/h 3,780 (1,460 ~ 4,640) 4,600 (1,460 ~ 6,190)
Moisture Removal gal/h 0.63 —
Running Current (Rated) A 5.92 - 5.35 6.81 - 6.16
Power Consumption Rated (Min. ~ Max.) W 1,150 (290 ~ 1,630) 1,340 (390 ~ 2,310)
Power Factor (Rated) % 93.5 - 93.5 94.6 - 94.6
COP Rated (Min. ~ Max.) W/W 3.82 (5.86 ~ 3.30) 4.00 (4.36 ~ 3.12)
EER Rated (Min. ~ Max.) Btu/h·W 13 (20 ~ 11.3) 13.7 (14.9 ~ 10.6)
SEER / HSPF 20.0 12.5
Piping
Connections
Liquid
in. (mm)
φ 1/4 (φ 6.4)
Gas
in. (mm)
φ 1/2 (φ 12.7)
Drain
in. (mm)
φ 5/8 (φ 16.0)
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 98-1/2 (30)
Max. Interunit Height Di󰀨erence ft (m) 65-5/8 (20)
Chargeless ft (m) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20)
Indoor Unit FTX15NMVJU
Front Panel Color White
Airow Rate H
cfm
(m³/min)
593 (16.8) 653 (18.5)
M 505 (14.3) 554 (15.7)
L 431 (12.2) 470 (13.3)
SL 367 (10.4) 399 (11.3)
Fan Type / Motor Output W Cross Flow Fan / 33
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.23 - 0.21 0.25 - 0.23
Power Consumption (Rated) W 33 - 33 38 - 38
Power Factor (Rated) % 69.0 - 68.3 73.1 - 71.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 39 × 10-3/8 (295 × 990 × 263)
Packaged Dimensions (H × W × D) in. (mm) 14-9/16 × 42-1/2 × 15-3/8 (370 × 1,080 × 390)
Weight (Mass) Lbs (kg) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 37 (17)
Sound Pressure
Level
H / M / L / SL
dB(A) 45 / 41 / 36 / 33 45 / 41 / 37 / 33
Outdoor Unit RXL15QMVJUA
Casing Color Ivory White
Heat Exchanger Fin / Spec. Tube
Wa󰀪e Fin (PE) / φ 7 mm Hi-XSL Tube
Compressor Type Hermetically Sealed Swing Type
Model 2YC36PXD
Motor Output W 1,100
Refrigerant Oil Type FVC50K
Charge oz (L) 21.5 (0.650)
Refrigerant Type R-410A
Charge Lbs (kg) 3.20 (1.45)
Airow Rate H
cfm
(m³/min)
2,044 (57.9) 2,044 (57.9)
SL 1,762 (49.9) 1,585 (44.9)
Fan Type / Motor Output W Propeller / 71
Running Current (Rated) A 5.69 - 5.14 6.56 - 5.93
Power Consumption (Rated) W 1,117 - 1,117 1,302 - 1,302
Power Factor (Rated) % 94.4 - 94.5 95.4 - 95.5
Starting Current A 6.81
Dimensions (H × W × D) in. (mm) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Packaged Dimensions (H × W × D) in. (mm) 31-7/8 × 41-9/16 × 18-1/4 (810 × 1,056 × 464)
Weight (Mass) Lbs (kg) 108 (49)
Gross Weight (Gross Mass) Lbs (kg) 123 (56)
Sound Pressure Level H dB(A) 50 55
Conditions Based on Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Drawing No. C: 3D127167
Notes SL: The quiet fan level of the airow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m3/min × 35.3
