Daikin FDMQ-R Series User Manual

FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
19
HANDLE
2-3/4 (70)34-1/4 (870)9/16 (14)
OUTDOOR AIR THERMISTOR
1/4 (7) 12-5/8 (320) 1-3/16 (30)
ELECTRIC WIRE INTAKE
BRAND NAME PLATE
TERMINAL STRIP COVER
MANUFACTURER'S LABEL
STOP VALVE COVER
3/4 (19)
28-15/16 (735)
7/8 (23)
9/16 (14.5)
4-15/16 (125)23-5/8 (600)
7/16 (11)13-5/8 (346)
14-1/2 (368)
*B
*A
*B
MINIMUM SPACE FOR AIR PASSAGE
11-7/16 (291)
GROUND
3-15/16 (100)
20-11/16 (525)*A
1-15/16 (50)1-15/16 (50) 1-15/16 (50)
13-3/4 (350)
3-15/16 (100)
3-15/16 (100)
13-3/4 (350)
4-1/8 (105) 6-1/2 (165)
13-3/4 (350)
UNIT: inch (mm)
6-13/16 (173)
4-HOLES FOR FOUNDATION BOLTS
5/16 OR 3/8 (M8 OR M10)
(INSTALLATION LEG
PITCH)
SERVICE
PORT
LIQUID
STOP VALVE
(φ1/4 (φ6.4) CuT)
GAS
STOP VALVE
(φ1/2 (φ12.7) CuT)
IN CASE OF REMOVING
STOP VALVE COVER AND
TERMINAL STRIP COVER
DRAIN OUTLET
(I.D φ5/8 (φ15.9) HOSE FOR
CONNECTION WITH DRAIN JOINT)
*A, *B DRAIN OUTLET
WHEN CONDUCTING CONCENTRATED
DRAIN PIPING WORK, ATTACH THE
SUPPLIED DRAIN CAPS.
WALL HEIGHT ON AIR OUTLET SIDE
= LESS THAN 47-1/4 (1200)
3D100006
RXL15QMVJUA
3D092206E
RXL09QMVJU, RXL12QMVJU9
4.2 Outdoor Unit
