10
FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
Model
Indoor Unit FVXS09NVJU FVXS12NVJU
Outdoor Unit
RXL09QMVJU RXL12QMVJU9
Cooling Heating Cooling Heating
Power Supply
1 φ , 60 Hz, 208 - 230 V 1 φ , 60 Hz, 208 - 230 V
Capacity Rated (Min. ~ Max.) kW 2.64 (1.30 ~ 3.00) 2.95 (1.30 ~ 4.20) 3.00 (1.30 ~ 3.60) 3.80 (1.30 ~ 5.00)
Btu/h 9,000 (4,400 ~ 10,200) 10,100 (4,400 ~ 14,300) 10,200 (4,400 ~ 12,300) 13,000 (4,400 ~ 17,100)
kcal/h 2,270 (1,120 ~ 2,580) 2,540 (1,120 ~ 3,610) 2,580 (1,120 ~ 3,100) 3,270 (1,120 ~ 4,300)
Moisture Removal gal/h 0.32 — 0.45 —
Running Current (Rated) A 3.75 - 3.39 3.67 - 3.32 4.20 - 3.80 4.69 - 4.24
Power Consumption Rated (Min. ~ Max.) W 720 (250 ~ 820) 720 (240 ~ 1.390) 850 (270 ~ 1,350) 950 (250 ~ 1,570)
Power Factor (Rated) % 92.3 - 92.3 94.3 - 94.3 97.3 - 97.3 97.4 - 97.4
COP Rated (Min. ~ Max.) W/W 3.66 (5.20 ~ 3.66) 4.10 (5.42 ~ 3.02) 3.52 (4.80 ~ 2.66) 4.00 (5.20 ~ 3.18)
EER Rated (Min. ~ Max.) Btu/h·W 12.5 (17.6 ~ 12.4) 14 (18.3 ~ 10.3) 12.0 (16.3 ~ 9.1) 13.7 (17.6 ~ 10.9)
SEER / HSPF 20.0 11.7 20.0 11.4
Piping
Connections
Liquid
in. (mm)
φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas
in. (mm)
φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain
in. (mm)
φ 13/16 (φ 20.0) φ 13/16 (φ 20.0)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 65-5/8 (20) 65-5/8 (20)
Max. Interunit Height Di󰀨erence ft (m) 49-1/4 (15) 49-1/4 (15)
Chargeless ft (m) 32-13/16 (10) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20) 0.21 (20)
Indoor Unit FVXS09NVJU FVXS12NVJU
Front Panel Color White White
Airow Rate H
cfm
(m³/min)
290 (8.2) 311 (8.8) 300 (8.5) 332 (9.4)
M 230 (6.5) 244 (6.9) 237 (6.7) 258 (7.3)
L 169 (4.8) 177 (5.0) 173 (4.9) 184 (5.2)
SL 145 (4.1) 155 (4.4) 159 (4.5) 166 (4.7)
Fan Type / Motor Output W Turbo Fan / 12.3 Turbo Fan / 13.4
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.14 - 0.13 0.15 - 0.14 0.14 - 0.13 0.15 - 0.14
Power Consumption (Rated) W 15 - 15 17 - 17 15 - 15 17 - 17
Power Factor (Rated) % 51.5 - 50.2 54.5 - 52.8 51.5 - 50.2 54.5 - 52.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210)
Packaged Dimensions (H × W × D) in. (mm) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280)
Weight (Mass) Lbs (kg) 31 (14) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 40 (18)
Sound Pressure
Level
H / M / L / SL
dB(A) 38 / 32 / 26 / 23 38 / 32 / 26 / 23 39 / 33 / 27 / 24 39 / 33 / 27 / 24
Outdoor Unit RXL09QMVJU RXL12QMVJU9
Casing Color Ivory White Ivory White
Heat Exchanger Fin / Spec. Tube
Wa󰀪e Fin (PE) / φ 7 mm Hi-XD Tube Wa󰀪e Fin (PE) / φ 7 mm Hi-XD Tube
Compressor Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AUXD 2YC36PXD
Motor Output W 790 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge oz (L) 12.4 (0.375) 21.5 (0.650)
Refrigerant Type R-410A R-410A
Charge Lbs (kg) 2.09 (0.95) 2.09 (0.95)
Airow Rate H
cfm
(m³/min)
1,105 (31.3) 922 (26.1) 1,144 (32.4) 1,006 (28.5)
SL 865 (24.5) 777 (22.0) 865 (24.5) 777 (22.0)
Fan Type / Motor Output W Propeller / 18 Propeller / 20
Running Current (Rated) A 3.61 - 3.26 3.52 - 3.18 4.06 - 3.67 4.54 - 4.10
Power Consumption (Rated) W 705 - 705 703 - 703 835 - 835 933 - 933
Power Factor (Rated) % 93.9 - 94.0 96.0 - 96.1 98.8 - 98.9 98.8 - 98.9
Starting Current A 3.76 4.54
Dimensions (H × W × D) in. (mm) 21-5/8 × 26-9/16 × 11-3/16 (550 × 675 × 284) 21-5/8 × 26-9/16 × 11-3/16 (550 × 675 × 284)
Packaged Dimensions (H × W × D) in. (mm) 24-3/4 × 32-11/16 × 16 (629 × 830 × 407) 24-3/4 × 32-11/16 × 16 (629 × 830 × 407)
Weight (Mass) Lbs (kg) 60 (27) 70 (32)
Gross Weight (Gross Mass) Lbs (kg) 71 (32) 80 (36)
Sound Pressure Level H dB(A) 49 49 50 50
Conditions Based on Indoor ; 80°FDB (26.7°CDB) /
67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) /
75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) /
43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 80°FDB (26.7°CDB) /
67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) /
75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) /
43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Drawing No. C: 3D101722 C: 3D123806
Notes SL: The quiet fan level of the airow rate setting. SL: The quiet fan level of the airow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m3/min × 35.3
