Daikin FDMQ-R Series User Manual

FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
13
Model
Indoor Unit FDMQ24RVJU
Outdoor Unit
RXL24UMVJUA
Cooling Heating
Power Supply
1 φ , 60 Hz, 208 - 230 V
Cooling Capacity (Min. ~ Max.)
4
kW
6.21 (2.64 ~ 7.03) 1 7.02 (2.64 ~ 8.09) 2
Btu/h
21,200 (9,000 ~ 24,000) 1 24,000 (9,000 ~ 27,600) 2
kcal/h
5,340 (2,270 ~ 6,050) 1 6,050 (2,270 ~ 6,960) 2
Heating Capacity
3, 4
kW — 4.69
Btu/h — 16,000
kcal/h — 4,030
COP (Min. ~ Max.) — 3.80 (5.38 ~ 2.66)
EER (Min. ~ Max.) 12.5 (15.8 ~ 11.4) —
SEER / HSPF 18.6 10.0
Indoor Unit FDMQ24RVJU
Casing Color —
Dimensions (H × W × D)
in. (mm) 9-5/8 × 39-3/8 × 31-1/2 (245 × 1,000 × 800)
Coil
Type Cross Fin Coil
Rows × Stages × Fin per inch 3 × 26 × 18
Face Area
ft² (m²) 3-1/8 (0.288)
Fan
Type Sirocco Fan
Motor Output W 230
Airow Rate H / M / L
cfm
(m³/min)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
External Static
Pressure
inH
2
O
0.20 (0.60 - 0.20) 5
Pa
50 (150 - 50) 5
Sound Pressure Level 40 40
Sound Power Level 54 54
Air Filter
— 6
Weight (Mass) / Gross Weight (Gross Mass)
Lbs (kg) 82 (37) / 88 (40)
Piping
Connections
Liquid
in. (mm)
φ 1/4 (6.4) (Flare)
Gas
in. (mm)
φ 5/8 (15.9) (Flare)
Drain
in. (mm)
I.D. φ 1 (25) / O.D. φ 1-1/4 (32)
Remote Controller
(Option)
Wired BRC1E73
Wireless BRC082A43
Outdoor Unit RXL24UMVJUA
Casing Color Ivory White
Dimensions (H × W × D)
in. (mm) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Coil
Type Cross Fin Coil
Rows × Stages × Fin per inch 2 × 32 × 18
Face Area
ft² (m²) 7-1/16 (0.658)
Compressor
Model 2YC63AAXD
Type Hermetically Sealed Swing Type
Motor Output
W 1,920
Fan
Type Propeller
Motor Output
W 76
Airow Rate
cfm
(m³/min)
2,418 (68.5) 2,361 (66.9)
Sound Pressure Level
dB(A) 55 55
Sound Power Level
dB(A) 67 67
Weight (Mass) / Gross Weight (Gross Mass)
Lbs (kg) 130 (59) / 137 (62)
Piping
Connections
Liquid
in. (mm)
φ 1/4 (6.4) (Flare)
Gas
in. (mm)
φ 5/8 (15.9) (Flare)
Drain
in. (mm)
I.D. φ 5/8 (16)
Safety Devices Fuse
Max. Interunit Piping Length
ft (m) 98-1/2 (30)
Max. Interunit Height Di󰀨erence
ft (m) 65-5/8 (20)
Chargeless
ft (m) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.32 (30)
Refrigerant Oil
Type FVC50K
Charge oz (L) 31.75 (0.900)
Refrigerant
Type R-410A
Charge Lbs (kg) 3.53 (1.60)
Drawing No.
C: 3D123805A
Notes
1 Indoor temp.: 80.0°FDB (26.7°CDB), 67.0°FWB (19.4°CWB) / Outdoor temp.: 95.0°FDB (35.0°CDB) / Equivalent piping length: 25
ft (7.6 m) / Level di󰀨erence: 0
2 Indoor temp.: 70.0°FDB (21.1°CDB) / Outdoor temp.: 47.0°FDB (8.3°CDB), 43.0°FWB (6.1°CWB) / Equivalent piping length: 25 ft
(7.6 m) / Level di󰀨erence: 0
3 Indoor temp.: 70.0°FDB (21.1°CDB) / Outdoor temp.: 17.0°FDB (-8.3°CDB), 15.0°FWB (-9.4°CWB) / Equivalent piping length: 25 ft
(7.6 m) / Level di󰀨erence: 0
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
5 External static pressure is changeable in 11 stages by remote controller.
6 Air lter is not standard accessory, but please mount it in the duct system of the suction side. Select its dust collection e󰀩ciency
(gravity method) 50% or more.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m3/min × 35.3
