FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
221
3P572320-1
6
Read Before Operation
Outdoor Unit
îš„ Open the front panel
Refrigerant pipes
Inter-unit wire
Ground terminals
(inside)
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name
Air îž‚lter
Titanium apatite
deodorizing îž‚lter
01_EN_3P572320-1.indd 6 2019/06/10 17:01:07
