Daikin FDMQ-R Series User Manual

52
FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
Cooling (60 Hz, 230 V)
AFR 19.9
BF 0.16
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 10 20 30 35 40 46
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 6.94 5.11 1.05 6.37 4.82 1.30 5.79 4.53 1.55 5.50 4.40 1.68 5.21 4.26 1.80 4.86 4.09 1.95
16.0 22.0 7.23 5.01 1.06 6.65 4.74 1.31 6.07 4.47 1.56 5.78 4.34 1.68 5.49 4.21 1.81 5.15 4.06 1.96
18.0 25.0 7.52 5.23 1.07 6.94 4.97 1.32 6.36 4.73 1.57 6.07 4.61 1.69 5.78 4.49 1.82 5.43 4.34 1.97
19.4 26.7 7.66 5.50 1.07 7.08 5.26 1.32 6.50 5.02 1.57 6.21 4.90 1.70 5.92 4.79 1.82 5.58 4.65 1.97
22.0 30.0 8.09 5.29 1.08 7.51 5.08 1.33 6.93 4.87 1.58 6.64 4.76 1.71 6.35 4.66 1.83 6.01 4.54 1.98
24.0 32.0 8.38 5.15 1.34 7.80 4.95 1.34 7.22 4.76 1.59 6.93 4.66 1.71 6.64 4.57 1.84 6.29 4.46 1.99
Temp: Fahrenheit / TC, SHC: kBtu/h / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 50 68 86 95 104 115
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 23.69 17.44 1.05 21.72 16.44 1.30 19.75 15.47 1.55 18.76 15.00 1.68 17.77 14.53 1.80 16.59 13.97 1.95
60.8 71.6 24.67 17.09 1.06 22.70 16.16 1.31 20.72 15.25 1.56 19.73 14.80 1.68 18.75 14.36 1.81 17.56 13.84 1.96
64.4 77.0 25.65 17.84 1.07 23.67 16.97 1.32 21.70 16.13 1.57 20.71 15.71 1.69 19.72 15.30 1.82 18.54 14.82 1.97
67.0 80.0 26.14 18.78 1.07 24.16 17.95 1.32 22.19 17.13 1.57 21.20 16.73 1.70 20.21 16.34 1.82 19.03 15.87 1.97
71.6 86.0 27.60 18.06 1.08 25.63 17.32 1.33 23.65 16.61 1.58 22.67 16.25 1.71 21.68 15.90 1.83 20.49 15.49 1.98
75.2 89.6 28.58 17.55 1.34 26.60 16.88 1.34 24.63 16.23 1.59 23.64 15.91 1.71 22.65 15.59 1.84 21.47 15.21 1.99
Heating (60 Hz, 230 V)
AFR 25.6
Temp: Celsius / TC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB -25 -20 -15 -10 -5 0 6 15.5
°C TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
15.0 5.26 2.91 6.21 3.27 7.18 3.64 7.44 3.49 7.72 3.33 8.01 3.17 8.37 2.98 10.10 3.22
21.1 4.72 3.00 5.73 3.37 6.74 3.74 7.06 3.58 7.38 3.41 7.70 3.25 8.09 3.05 9.82 3.29
22.0 4.50 3.03 5.54 3.41 6.56 3.79 6.91 3.62 7.25 3.45 7.58 3.28 7.98 3.08 9.71 3.32
24.0 4.28 3.07 5.35 3.45 6.39 3.83 6.76 3.65 7.11 3.48 7.46 3.31 7.87 3.11 9.60 3.34
25.0 4.18 3.09 5.25 3.47 6.30 3.85 6.68 3.67 7.04 3.50 7.40 3.33 7.81 3.12 9.55 3.36
27.0 3.26 2.30 5.06 3.51 6.12 3.89 6.53 3.71 6.91 3.53 7.27 3.36 7.70 3.15 9.43 3.38
Temp: Fahrenheit / TC: kBtu/h / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB -13 -4 5 14 23 32 43 60
°F TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
59.0 17.95 2.91 21.18 3.27 24.51 3.64 25.40 3.49 26.35 3.33 27.34 3.17 28.55 2.98 34.47 3.22
70.0 16.10 3.00 19.55 3.37 23.00 3.74 24.10 3.58 25.19 3.41 26.29 3.25 27.60 3.05 33.52 3.29
71.6 15.36 3.03 18.90 3.41 22.40 3.79 23.57 3.62 24.73 3.45 25.87 3.28 27.22 3.08 33.14 3.32
75.2 14.62 3.07 18.24 3.45 21.79 3.83 23.05 3.65 24.26 3.48 25.45 3.31 26.84 3.11 32.76 3.34
77.0 14.25 3.09 17.92 3.47 21.49 3.85 22.79 3.67 24.03 3.50 25.24 3.33 26.65 3.12 32.57 3.36
80.6 11.14 2.30 17.26 3.51 20.89 3.89 22.27 3.71 23.57 3.53 24.82 3.36 26.27 3.15 32.19 3.38
Symbols:
AFR
BF
EWB
EDB
TC
SHC
PI
: Airflow rate
: Bypass factor
: Entering wet bulb temp.
: Entering dry bulb temp.
: Total capacity
: Sensible heat capacity
: Power input
Notes:
(m³/min.)
(°C) / (°F)
(°C) / (°F)
(kW) / (kBtu/h)
(kW) / (kBtu/h)
(kW)
shows nominal (rated) capacities and power input (Cooling) and MAX
capacities and power input (Heating).
1.
TC, PI and SHC must be calculated by interpolation using the figures in the above
tables.
(Figures out of the tables should not be used for calculation.)
2.
Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25 ft (7.5 m)
Level difference : 0 ft (0 m)
3.
Airflow rate (AFR) and Bypass factor (BF) are tabulated above table.4.
C: 3D123798
