Daikin FDMQ-R Series User Manual

54
FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
7.1.3 24 Class
— line: cooling capacity
--- line: heating capacity
Range of the refrigerant additional charge
Capacity correction factor
16.4 32.8 49.2 65.6 82.0 (ft)
5 10 15 20 25
98.4
30 (m)
(R-410A)
Piping length
80
90
100
(%)
Note: The graphs show the factor when additional refrigerant of the proper quantity is charged.
