Si041264EC Front Grille
Removal Procedure 5
4. Front Grille
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1 Remove the 2 screws.
2
3
Unfasten the 3 hooks at
the top.
Pull out the upper part
of the front grille, lift up
the lower part, and then
remove the front grille.

The convex marks (...) on
the front panel indicate the
position of the hooks.

When reassembling, make
sure that all the 3 hooks are
fastened.
(R11631)
Front grille
(R18189)
Hook
(R12715)
