Si041144 Removal of Horizontal Blades / Swing Motors
Removal Procedure 25
2
Remove the interlock
rod (2) with pliers.
3
Remove the interlock
rod (1).
Step Procedure Points
(R9553)
Interlock rod (2)
(R9554)
(R9555)
Interlock rod (1)
