Removal of Fan Motor / Fan Rotor Si041144
32 Removal Procedure
2
Release the fan motor
harness from the hook.
3
Loosen the screw of the
fan rotor.
Step Procedure Points
(R16973)
(R16304)
Fan rotor
(R9648)
