Si041251EC
Fan Motor
Remo
val P
roced
ure
15
8.
Fan Motor
War
ni
ng
î
Be sure to wait for
10 minutes or more after tu
rning off al
l power supplies bef
ore
disassembling work.
Step
Procedure
Points
1
Release the f
an motor
lead wires
from the
hooks.
2
Remove the screw of
the fan r
otor.
3
4
Remove the 2 screws
of the f
an motor f
ixi
ng
plate.
Unfasten the hook
(a)
of the f
an motor f
ixi
ng
plate.
(R4389)
(R4390)
Hook (a)
(R20215)
Fan motor
fixing plate
16
18
