Daikin FTKV35NVM - Page 23

Si041251EC Fan Rotor
Removal Procedure 21
7
Remove the screw of
the left side plate.
8
Unfasten the 2 hooks
and remove the left side
plate.
9
Press the bearing from
the outside and remove
the bearing.
Step Procedure Points
(R4414)
Left side
plate
(R4415)
Hook
Hook
Bearing
(R4416)
