7 | Maintenance and service
User reference guide
32
FTXP20~35N5V1B9 + ATXP20~35N5V1B9
Daikin room air conditioner
4D520466-17M – 2023.08
7.4 About the air filters
Operating the unit with dirty filters means that the filter:
▪ CANNOT deodorise the air,
▪ CANNOT clean the air,
▪ poor heating/cooling,
▪ causes odour.
7.5 To open the front panel
1 Hold the front panel by the panel tabs on both sides and open it.
7.6 To clean the air filters
1 Push the tab at the centre of each air filter, then pull it down.
2 Pull out the air filters.
3 Remove the titanium apatite deodorising filter and silver particle filter from
the tabs.
a Tab
4 Wash the air filters with water or clean them with a vacuum cleaner.
