Piping Diagrams SiUS041829E
134 Part 8 Appendix
1. Piping Diagrams
1.1 Indoor Unit
FTXR09/12TVJUW(S)
FTXR18TVJUW(S)
Indoor unit
1/4 CuT
3/8 CuT
Heat exchanger thermistor
Heat exchanger
Cross flow fan
Fan motor
Field piping
3/8 CuT
Field piping
1/4 CuT
Refrigerant flow
Cooling
Heating
4D101008A
Indoor unit
1/4 CuT
3/8 CuT
Heat exchanger thermistor
Heat exchanger
Cross flow fan
Fan motor
Field piping
1/2 CuT
Field piping
1/4 CuT
Refrigerant flow
Cooling
Heating
4D101010A
