Si01-406 FT25/35CV1A, FTY25/35CVMA
Removal Procedure 129
1.2 Removal of Front Grille
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1. Remove the service cover.
1
Remove a service
cover mounting screw.
Open service cover
upward.
A switch for field setting is
not provided in particular.
To Next Page
