Daikin FTY25CVMA - 2. FT50;60 CV1 A Component Removal

Si01-406 FT25/35CV1A, FTY25/35CVMA
Removal Procedure 137
2. Remove the printed circuit
board (PCB).
1
Remove the shelter.
2
Disengage the front
plate of the electrical
parts box.
Disengage the knobs
by pushing the two
hooks at the top and the
bottom.
3
Sliding to the left, the
front part of the
electrical parts box can
be removed.
Step Procedure Points
