Removal of PCBs (Pattern 1)
Si041137
16
Removal Procedu
re
3
Remove the si
gnal
recei
ver unit
.
4.
Remove the
INTELLI
GENT EYE
sensor PCB.
1
Unfasten t
he 3 hooks
and remove the
INTELLIGENT EYE
sensor PCB.
2
Disconnect
the
connector
[S26] f
rom
the I
NTELLIGENT EYE
sensor PCB.
Step
Procedure
Points
(R12278)
Hook
(R8088)
Signal receiver unit
(R8092)
INTELLIGENT EYE
sensor PCB
(R8093)
[S26]
17
19
