Daikin LRLEQ5AY1(E) - Page 32

SiENBE28-901 Field Settings
Air Cooled Refrigeration Condensing Unit 31
Tsd: The evaporation temperature set by the dip switches.
DS1
Tsd
DS1
Tsd
LRMEQ** LRLEQ** LRMEQ** LRLEQ**
-10°C
(0.47MPa)
-35°C
(0.11MPa)
0°C
(0.69MPa)
-25°C
(0.22MPa)
-20°C
(0.29MPa)
-45°C
(0.03MPa)
5°C
(0.82MPa)
-20°C
(0.29MPa)
-15°C
(0.37MPa)
-40°C
(0.07MPa)
10°C
(0.98MPa)
-5°C
(0.56MPa)
-30°C
(0.16MPa)
ON
OFF
1234
Factory set
ON
OFF
1234
ON
OFF
12 34
ON
OFF
1234
ON
OFF
1234
ON
OFF
1234
ON
OFF
1234
ON
OFF
1234
Factory set
