Field Settings SiENBE28-901
38 Air Cooled Refrigeration Condensing Unit
d. Setting method with the AIRNET or type-III checker.
1) In case of the AIRNET
• Use Setting Mode 2-6 (AIRNET address).
• Use Setting Mode 2-16 (virtual indoor unit address).
2) In case of a Type-III checker
• Use Setting Mode 2-16 (virtual indoor unit address).
No.
Display of setting items
Display of setting conditions
Setting item H1P H2P H3P H4P H5P H6P H7P
6 AIRNET address
khhhkkh
16 Virtual indoor unit address setting
khkhhhh
• When there is 1 outdoor unit, set the
address to "1".
• When there are multiple outdoor units
(outdoor-outdoor transmission
connection), contact the After Sales
Service Division.
H1P H2P H3P H4P H5P H6P H7P Please give the
address of 1 or
more to when you
do the AIRNET.
Uses binary
numbers for the
address (six digits).
(Factory set) 0 khhhhhh
1 khhhhhk
~
63 kkkkkkk
H1P H2P H3P H4P H5P H6P H7P
(Factory set) 0 khhhhhh
1 khhhhhk
~
63 kkkkkkk
