Conversion table for using the evaporation temperature (set by the dip switches) to determine
its pressure equivalent
DS1
Tsd(Lpm1)
DS1
Tsd(Lpm1)
LRMEQ** LRLEQ** LRMEQ** LRLEQ**
-10°C
(0.47MPa)
-35°C
(0.11MPa)
0°C
(0.69MPa)
-25°C
(0.22MPa)
-20°C
(0.29MPa)
-45°C
(0.03MPa)
5°C
(0.82MPa)
-20°C
(0.29MPa)
-15°C
(0.37MPa)
-40°C
(0.07MPa)
10°C
(0.98MPa)
-5°C
(0.56MPa)
-30°C
(0.16MPa)
ON
OFF
1 2 3 4
Factory set
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
