SiENBE28-901 Description of Functions and Operation
Air Cooled Refrigeration Condensing Unit 53
(4)-5. Outdoor fan tap table
 LRM(L)EQ5AY1
 LRM(L)EQ6AY1
 LRM(L)EQ8AY1
 LRM(L)EQ10AY1
 LRM(L)EQ12AY1
 LRM(L)EQ15AY1
 LRM(L)EQ20AY1
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 285 315 360 450 570 730 800 850 951
Fan (Fan tap) 0123456789
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 285 315 360 450 570 730 850 1000 1020
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 285 315 360 450 570 800 951 1000 1020
Fan (Fan tap) 012345678
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 285 315 360 450 570 800 951 1020
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 350 370 400 460 530 630 680 710 760
Fan (Fan tap) 0123456789
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 350 370 400 460 560 630 680 795 870
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 350 370 400 460 530 630 710 760 795
Fan (Fan tap) 0123456789
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 350 370 400 460 560 630 760 821 870
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 350 370 400 460 560 680 795 821 850
Fan (Fan tap) 012345678
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 350 370 400 460 560 680 795 870
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 395 800 460 570 720 800 1050 1136 1186
0 0 0 395 540 690 770 1020 1106 1156
Fan (Fan tap) 012345678
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 395 800 460 570 720 800 1136 1235
0 0 0 395 540 690 770 1106 1205
Fan (Fan tap) 0123456789
Outdoor fan (standard mode)
Revolution (rpm)
0 395 800 460 570 800 930 1136 1186 1235
0 0 0 395 540 770 900 1106 1156 1205
Fan (Fan tap) 012345678
Outdoor fan (high static pressure mode)
Revolution (rpm)
0 395 800 460 570 800 930 1136 1235
0 0 0 395 540 770 900 1106 1205
