2.2 Controller Functions List
The controller installed in this unit has following functions. Access to the pertinent item in following pages
for detail.
Items Function Paragraph No.
Setting
Temperature SP, Humidity SP, Bulb mode 2.3 ※1, 2-2, 2-3
Defrost Interval AUTO or 3, 6, 9, 12 or 24Hr 2.3 ※2-1
ASC (Automatic Set-point Change) 2.3 ※2-5
USDA 2.3 ※2-4, 1.5.2
ACT (Automatic Cold Treatment) 2.3 ※2-6, 1.5.3
Fan Speed Control 2.3 ※2-8
G-Set (Power limit setting for Gen set operation) 2.3 ※2-7
PTI Short PTI, Chilled PTI, Frozen PTI, Full PTI 3.3
Service
Manual
Check
ON/OFF check
PCC1, PCC2,
CFH, CFL, EFH, EFL with motor current
display HSV, RSV, LSV, ESV
4.1 ※1〜※10
RM Circuit Check 4.1 ※11
HuS Reading 4.1 ※12
Sensor Calibration SS, DSS, RS, DRS, FA 4.1 ※13〜※18
Trip Start Time and reset 4.1 ※19
Running hours and reset CM, EFH, EFL, CFH, CFL 4.1 ※20〜※24
Sensor
Information
(Air) SS, DSS, RS, DRS, Hus, AMBS (Cargo) USDA1, 2, 3, CTS
(Ref.) EIS, EOS, DCHS1 & 2, SGS, ECO-IN, ECO-OUT
(Ventilation) FA (Pressure) HPT, LPT
(Power) Battery Voltage, Supply Voltage, Total & Comp.
Current
2.3 ※3
Service
Menu
Trip Chart, Trip Report, PTI History, Alarm Record 2.3 ※5
Automatic Pump-down 2.3 ※5-5
Monitoring Data logging 2.3 ※5-6
LCD Back Light setting 2.3 ※6
Unit Convert 2.3 ※7
Manual Defrost 2.3 ※8
Current Alarm Display 2.3 ※9
Data Download, Software Upload using USB memory 2.3 ※14
Battery
Mode
Data
Information
Setting
Unit ON/OFF
SP, Humidity SP, Defrost Interval
2.3 ※15
Sensor Information
SS, RS, USDA1, 2, 3, CTS, FA,
HPT, LPT
Battery Voltage
2.3 ※15
PTI History, Software Version 2.3 ※15
Alarm Record, Trip Chart 2.3 ※15
Data Download, Software Upload using USB memory 2.3 ※14
