3
4.10 External Receptacle Wiring Diagrams …… 4-27
4.10.1 Power Plug (P1) ……………………… 4-27
4.10.2 PC Port Receptacle (PPR1, 2) ……… 4-27
4.10.3 Remote Monitoring Receptacle
(RM; option) …………………………… 4-27
4.10.4 USDA Sensor 1 to 3 Receptacles
(USDA 1 to 3; options) ……………… 4-27
Cargo Temperature Sensor Receptacle
(CTR; option) ………………………… 4-27
Chapter 5 Air/Water-Cooled Type (Option) …… 5-1
5.1
Operation Range and Main Specifications
……… 5-2
5.1.1 Operation Range ………………………… 5-2
5.1.2 Main Specifications ……………………… 5-2
5.2 Protective Device and Setpoints ……………… 5-3
5.3 Construction …………………………………… 5-4
5.3.1 Outside View ……………………………… 5-4
5.3.2
Piping System Diagram and Sensor Location
… 5-4
5.4 Operation ……………………………………… 5-5
5.5 Operation Mode and Control ………………… 5-6
5.5.1 Water-cooled Operation ………………… 5-6
5.5.2
Condenser Fan Control during Water-cooled Operation
… 5-6
5.6 Parts Replacement …………………………… 5-7
5.6.1 Cooling Water Pressure Switch ………… 5-7
Chapter 6 APPENDIX …………………………… 6-1
6.1
Standard Tightening Torque for Bolt and Flare Nut
… 6-2
6.2 Temperature Sensor Characteristics ………… 6-3
●
SS/RS/DSS/DRS/EIS/EOS/Eco In/Eco Out/SGS/AMBS
… 6-3
●
DCHS Sensor Characteristics DCHS1/DCHS2
… 6-4
● NTC type USDA Sensor Characteristics,
USDA1, USDA2, USDA3, CTS (Option) …… 6-5
●ST9702-1 type USDA Sensor Characteristics,
USDA1, USDA2, USDA3, CTS (Option) …… 6-6
6.3 Pressure Sensor Characteristics …………… 6-7
6.4
Humidity Sensor Characteristics, HuS (Option)
… 6-7
6.5 R134a Characteristics ………………………… 6-8
6.6 Sequence ……………………………………… 6-9
