Daikin MicroTech II User Manual

OM 752-4 12 www.DaikinApplied.com
Display
Keypad menu
item list
Abr. Description
RO
RW
1
06 Default
x5
Exhaust Interlock OAD
Min Position set point
EOAD
Adjust OA damper position above which the exhaust fan output will be energized. There is a xed –5%
differential associated with this set point.
RW x 99%
x6
Energize Exhaust Fan
OAD Set point
OADE Adjust OA damper minimum position when the exhaust interlock input is energized. RW x 12%
x7
OAD Max Position Set
point
OAMX Adjust OA damper maximum position. RW x 99%
x8
OAD Lockout Enable
Set OA damper lockout feature status: 0 = disable, 1 = enable. (This variable is factory set to 1 when
the unit is ordered as a recirc unit with no OAD.)
RW x 0
x9
OAD Lockout Set
point
OALS
Adjust OA temperature below which the OA damper closes if the OA damper lockout is enabled. (This
variable is factory set to –99°C when the unit is ordered as a recirc unit with no OAD.)
RW x
35.6°F
(2°C)
e1
Economizer Enable Set economizer status: 0 = disable, 1 = enable. RW x 1
e2
Economizer OA Temp
Set point
ETS
Adjust economizer OA temperature set point. DO NOT lower this set point below CCLO or you risk
creating a deadband where no cooling occurs.
RW x
68°F
(20°C)
e3
Economizer IA/OA
Temp Differential
ETD Adjust economizer IA/OA temperature differential. RW x
1.8°F
(1°C)
e5
Economizer OA En-
thalpy Set point
EES Adjust economizer OA enthalpy set point. RW x
25 Btu/lb
(58 kJ/kg)
e6
Economizer IA/OA
Enthalpy Differential
EED Adjust economizer IA/OA enthalpy differential. RW x
1.3 Btu/lb
(3 kJ/kg)
r1
Space Humidity Output ERH Display room humidity (optional). 00 = No sensor connected. RO x
r3
Outdoor Air Humidity
Output
EORH Display OA humidity (optional). 00 = No sensor connected. RO x
xt
Outdoor Air Temp Output EOAT Display OA temperature. RO x
h1
Emergency Heat Enable Set emergency heat status: 0 = disable, 1 = enable. RW x 1
h2
Emergency Heat
Set point
EHS Adjust emergency heat set point. RW x
53.6°F
(12°C)
h3
Emergency Heat Shut-
down Conguration
Set emergency heat operation during shutdown, 0 = no emergency heat during shutdown: 1 = allow
emergency heat during shutdown.
RW x 0
b3
External BI-3 Congu-
ration
Set the function external binary Input 3: 0 = ventilation lockout, 1 = exhaust interlock. RW x 0
cf
Fan Cycling
Conguration
Set space fan cycles (switches off) during occupied, bypass, and standby mode: 2 = continuous, 3 =
cycling.
RW x 2
ce
Filter Alarm Enable Set lter alarm status: 0 = disable, 1 = enable. RW x 0
cr
Reset Filter Alarm Input Enter 1 to clear lter alarm. RW x
2
sp
Space Temp Sensor
Offset
Adjust this setting to bias the UVC measured space temperature. RW x 0
un
Keypad/display
Temperature Units
Set keypad/display temperature units in English or SI. This set point also effects which unit types dis-
played over Metasys N2 and BACnet MS/TP networks using the appropriate optional communications
modules.
RW x F
1. RW = read and write capable, RO = read only.
2. If a menu value is greater than 2-digits (higher than 99), then will be displayed on the keypad/display.
GettInG started
